1. A spring is stretched by 0.20 m, when a mass of
0.50 kg is suspended. When a mass of 0.25 kg is
suspended, then its period of oscillation will be (g = 10 m/ \[s^{2}\] )
a) 0.328 sec
b) 0.628 sec
c) 0.137 sec
d) 1.00 sec
Explanation:
2. A mass M is suspended from a spring of negligible
mass. The spring is pulled a little and then
released so that the mass executes simple
harmonic oscillations with a time period T. If the
mass is increased by m then the time period
becomes \[\left(\frac{5}{4}T\right)\] .The ratio of
\[\left(\frac{m}{M}\right)\] is
a) 9/16
b) 25/16
c) 4/5
d) 5/4
Explanation:
3.A spring having a spring constant ‘K’ is loaded
with a mass ‘m’. The spring is cut into two equal
parts and one of these is loaded again with the
same mass. The new spring constant is
a) K/2
b) K
c) 2K
d) \[k^{2}\]
Explanation:
4. A weightless spring which has a force constant
oscillates with frequency n when a mass m is
suspended from it. The spring is cut into two
equal halves and a mass 2m is suspended from it.
The frequency of oscillation will now become
a) n
b) 2n
c) \[n/\sqrt{2}\]
d) \[n\left(2\right)^{1/2}\]
Explanation:
5. A mass M is suspended from a light spring. An
additional mass m added displaces the spring
further by a distance x. Now the combined mass
will oscillate on the spring with period
a) \[T=2\pi\sqrt{\left(mg/x\left(M+m\right)\right)}\]
b) \[T=2\pi\sqrt{\left(\left(M+m\right)x/mg\right)}\]
c) \[T=\left(\pi/2\right)\sqrt{\left(mg/x\left(M+m\right)\right)}\]
d) \[T=2\pi\sqrt{\left(\left(M+m\right)/mgx\right)}\]
Explanation:
6. In the figure, S1 and S2 are identical springs. The
oscillation frequency of the mass m is f . If one
spring is removed, the frequency will become
a) f
b) \[f\times 2\]
c) \[f\times \sqrt{2}\]
d) \[f/ \sqrt{2}\]
Explanation:
7. The vertical extension in a light spring by a
weight of 1 kg suspended from the wire is 9.8 cm.
The period of oscillation
a) \[20\pi\] sec
b) \[2\pi\] sec
c) \[2\pi/10\] sec
d) \[200\pi\] sec
Explanation:
8. A particle of mass 200 gm executes S.H.M. The
restoring force is provided by a spring of force
constant 80 N / m. The time period of oscillations
is
a) 0.31 sec
b) 0.15 sec
c) 0.05 sec
d) 0.02 sec
Explanation:
9. The length of a spring is l and its force constant is
k. When a weight W is suspended from it, its
length increases by x. If the spring is cut into two
equal parts and put in parallel and the same
weight W is suspended from them, then the
extension will be
a) 2 x
b) x
c) \[\frac{x}{2}\]
d) \[\frac{x}{4}\]
Explanation:
10.A block is placed on a frictionless horizontal table.
The mass of the block is m and springs are attached on either side with force constants \[k_{1}\]
and \[k_{2}\] . If the block is displaced a little and left to
oscillate, then the angular frequency of oscillation
will be
a) \[\left(\frac{k_{1}+k_{2}}{m}\right)^{1/2}\]
b) \[\left(\frac{k_{1}k_{2}}{m\left(k_{1}+k_{2}\right)}\right)^{1/2}\]
c) \[\left(\frac{k_{1}k_{2}}{\left(k_{1}-k_{2}\right)m}\right)^{1/2}\]
d) \[\left(\frac{k_1^2+k_2^2}{\left(k_{1}+k_{2}\right)m}\right)^{1/2}\]
Explanation:
